Slim60 Casement Door

Specification	Details
Series	Slim60 Casement Door
System Door Types	Interior Casement Door
Profile Thickness	1.6mm
Glass Configuration	4mm+20A+4mm Tempered insulated glass
Sash Dimensions	Sash Width: 60mm
Installation Flange Width	Single casing / Interior Single casing： 61mm （Wall-Side Depth） Standard Frame: 75mm （Wall-Side Depth）
Recommended Size Range	Sash width: 600mm -1000mm Sash height: 1800mm -2700mm Note: An additional set of hinges is required when the sash height exceeds 2600mm. Please refer to the size limitation chart for specific structural limits. If the dimensions exceed the allowable range, please consult customer service and obtain special technical approval before placing your order.
Hardware	Proprietary Handles and Hardware
Color Options	Standard：Cool Moon Gray/Luminescent Gold/Phantom Black/Phantom White Optional :Light cloud curry/Jade Green/Mocha Brown/Starry Black/Waklnut/Red Teak/ Red Sandalwood/Rosewood Gold
Core Advantages	60mm Slim Sightline: High structural integrity with a streamlined, clean appearance. Glazing: 20mm insulated glass for optimized sound insulation. Sash Design: Rectangular profile with micro-chamfered/beveled corners. Hardware: Signature minimalist handle with unique linear aesthetics.
Applicable Venues	Bathroom, Kitchen
