IDEA10Pro Top-hung Sliding Door

Specification	Details
Series	IDEA10Pro Top-hung Sliding Door
System Door Types	Interior Top-Hung Sliding Door
Main Profile Thickness	2.2mm
Glass Configuration	8mm Tempered Glass
Sash Dimensions	10mm (Front Face, excluding 7.5mm rib decorative face) × 45mm (Thickness)
Track Frame Dimensions	Single Track (Wall-mount): 60 mm Double Track (Wall-mount): 111 mm Triple Track (Wall-mount): 162 mm
Opening Configurations	Single Track, Single Panel (1T1P) Single Track, 2-Panel (1T2P) Double Track, 2-Panel (2T2P) Double Track, 4-Panel (2T4P) Triple Track, 3-Panel (3T3P) Quadruple Track, 4-Panel (4T4P) Quintuple Track, 5-Panel(5T5P)
Applicable Door Types	3-Panel Telescopic(Optional), 4-Panel Telescopic(Optional), 5-Panel Telescopic(Optional)
Recommended Size Range	Top-hung Sliding Door: Sash Width(W): 400 mm – 1500 mm Sash Height(H): 1700 mm – 2800 mm Standard Sliding Door: Sash Width(W): 480 mm (Single Soft-close) / 750 mm (Double Soft-close) – 1500 mm Sash Height(H): 1700 mm – 2800 mm Please refer to the size limitation chart for specific structural limits. If the dimensions exceed the allowable range, please consult customer service and obtain special technical approval before placing your order.
Hardware	Lock & Handle: V12 Minimalist Handle Sliding Door: Standard Single Soft-Close Top-Hung Door: Standard Dual Soft-Close
Color Options	Standard：Cool Moon Grey/Luminescent Gold/Phantom Black/Phantom White/Aurora Grey Optional :Light cloud curry/Jade Green/Mocha Brown/Starry Black/Waklnut/Red Teak/Red Sandalwood/Rosewood Gold
Core Advantages	10mm ultra-slim interlock sightline: Maximizing natural light and transparency. Fully concealed hardware: Delivering precision millimeter-level clearances. Multi-panel linkage: Engineered for a silky-smooth, effortless initial glide. Integrated lock and handle: Eliminating complexity for a pure, seamless user experience. Triple-panel linkage design: Offering a fluid and seamless sliding experience. 90° barrier-free corner: Extending spaces with uninterrupted horizons. Flush triple-panel design: Saving two-thirds of the stackable opening space. Integrated damping system: Providing anti-slamming and finger-pinching protection. Flush embedded glazing: Eliminating exterior silicone sealant for a clean, flawless aesthetic.
Applicable Venues	Kitchen, Study Room, Cloakroom
