Essen 115 Thermal Break Casement Door

Specification	Details
Series	Essen 115 Thermal Break Casement Door
System Door Types	Exterior Thermal Break Casement Door
Profile Thickness	2.2mm
Glass Configuration	5mm+20A+5mm Tempered insulated glass (Standard with black corrugated aluminum spacer)
Overall Frame Dimensions (OFD)	Frame Depth: 115mm
Sash Depth	W 95mm × D 78.1mm (W = Face Width, D = Sash Depth)
Maximum Size Range of Opening Sash	Sash Width(W): 500 mm – 1000 mm Sash Height(H): 1800 mm – 2600 mm Please refer to the size limitation chart for specific structural limits. If the dimensions exceed the allowable range, please consult customer service and obtain special technical approval before placing your order.
Thermal break depth	25.3mm（BaiYun Yile)
Hardware	Swing Door Hardware (Outswing / Inswing) — Glass Leaf & Mesh Leaf: Wehag Handle + Wehag Anti-Pry Locking System Double Door / Unequal Double Door Hardware: Active Leaf: Wehag Door Handle (M5 Outdoor) + Wehag K-Series Lock Body + Wehag Multi-Point Locking System + Wehag Barrel Hinges Passive Leaf: Wehag Interlocking Flush Bolt System + Wehag Barrel Hinges
Opening Mode	Outswing Hinged Door,Outswing Door + Inswing Screen (Stainless Steel Screen Mesh/High-transparency Screen Mesh/High-transparency Stainless Steel Screen Mesh),Inswing Hinged Door,Inswing Door + Outswing Screen (Stainless Steel Screen Mesh/High-transparency Screen Mesh/High-transparency Stainless Steel Screen Mesh),Unequal Double Door / Double Hinged Door,Door-Window Combination Unit Optional: Compatible with Z2 Pleated Screen
Color Options	External Color：Cold Moon Grey/Mocha Brown/Luminescent Gold/Starry Black/Phantom White Optional :Light cloud curry/Jade Green Internal Color：Cold Moon Grey/Mocha Brown/Luminescent Gold/Starry Black/Phantom White Optional :Light cloud curry/Phantom Black/Waklnut/Red Teak/Red Sandalwood/Rosewood Gold
Core Advantages	2.2mm Profile Thickness: Engineered for exceptional wind load resistance and zero-rattle structural stability. Two-Part 4.0 Corner Injection: Comprehensive glue-injection technology upgrades weather-tightness, ensuring a waterproof, moisture-proof, and safer home. Integrated Window & Screen: A seamless, sleek aesthetic that effortlessly keeps mosquitoes and pests out. German WEHAG Hardware: High-security anti-theft and anti-pry system for absolute peace of mind. Stepped Visible Drainage: Minimalist design with innovative drainage caps that ensures efficient water evacuation while preventing backflow and insects.
Applicable Venues	Garden Entrance, Patio Doors, Sunroom
